6ES7 331-7FK02-0AB0 – Siemens
In-Stock: 1
Available, can ship immediately
Part Details:
Analog Input Module
Model : 6ES7 331-7FK02-0AB0.
Rated value(DC) : 24V.
Reserve polarity protection : Yes.
From load voltage L+(Without load), max : 200mA.
from backplane bus 5VDC,max : 50mA.
Power loss, typ. : 1W.
No Of Analog inputs : 8.
No of analog inputs for resistance measurement : 4.
Permissible input voltage for voltage input, max : 20V; continuous; 75V
for max. 1s(mark to space ratio 1:20)
Permissible input current for current input, max : 40mA.
Optically isolated, 8AI,Resolution 9/12/14 BITS,U/I/thermocouple/resistance interrupt,1x20 PIN remove/insert W. backplane bus.
